Product Specifications
• Speed Range: 0.7 to 15.5 L/min
• Tip Sizes: 4.5 mm, 6.5 mm, 8.5 mm, 10.5 mm
• Hopper Capacity: 50 L
• Operating Pressure: Max. 20 bar
• Mortar Hose: 40 bar operating pressure
• Operating Distance: Approx. 20 m
• Noise Emission: 70 dB(A)
Operating Conditions
• Ambient Temperature Range: 2–45 °C
• Relative Humidity: Max. 80%
Dimensions & Weight
• Total Weight: Approx. 40 kg
• Weight (dismantled for transport): 29 kg
• Housing: 2.6 kg
• Worm Pump: 1.5 kg
• Material Hopper: 3.6 kg
• Height: 1045 mm
• Length: 780 mm
• Width: 415 mm
Electrical Specifications
• Cable Diameter: Min. 3x1.5 mm²
• Power Supply: Max. length 25 m
• Nominal Power: 1.5 kW
• Connection: 1x230 V / 50 Hz
• Protection: Max. 1x16 A (construction site distributor with RCD safety switch, I=30 mA)
